    SRD.TGG.2K.308 8 Pin Electrical Connectors Multipole Waterproof Multi Pin Connector

    Ask Lasest Price
    Brand Name : Sreada
    Model Number : TGG.2K.308
    Supply Ability : 5000 Set/Sets per Week
    Price : $3.00 - $30.00/Sets
    • Product Details
    • Company Profile

    SRD.TGG.2K.308 8 Pin Electrical Connectors Multipole Waterproof Multi Pin Connector

    TGG.2K.308 8 Pins Multipole Waterproof Straight K Series Wire Multi Pin Precision Connector

    K Series connector with the following main features:

    · Smart push-pull self-latching system.
    · Multi-core types with 2 to 32 pins.
    · Solder or PCB contacts(straight and elbow).
    · Diferent kinds of keying opltions to avoid mismatching.
    · 360 degree screening for fullEMC shielding.
    · Waterproof connector (IP65 to 68).
    · Rugged housing for extreme working conditions.
    · High packing density for space savings.

    · Endurance >5000 cycles
    · Humidity.up to 95%at 60℃
    · Temperature range:-45°~+125°
    · Resistance to vibration:10-20000Hz,15g
    · Shock resistance:100g.6ms
    · Salt spray corrosion test >48h
    · Protection IP66~IP68

    K series connectors are available in the following specifications

    0K: cut-out panel size is M14mm, core number: 1-9 core
    1K: cut-out panel size is M16mm, core number: 1-14 core
    2K: cut-out panel size is M20mm, core number: 1-26 core
    3K: The size of the opening panel is M24mm, the number of cores: 2-32 cores
    4K: cut-out panel size is M30mm, core number: 2-64 core


    We provide the most extensive product line in the industry, and at the same time we recognize the particularity of practical application requirements. If the existing products can not meet the customer's needs, Shenruida (SRD) can design and produce according to the actual needs of customers.
    By using the industry's most advanced engineering development tools and innovative design, SRD can provide customers with personalized solutions. These powerful tools enable Shenruida (SRD) to demonstrate the feasibility of products including prototype development in just days or weeks instead of months.

    SRD.TGG.2K.308 8 Pin Electrical Connectors Multipole Waterproof Multi Pin ConnectorSRD.TGG.2K.308 8 Pin Electrical Connectors Multipole Waterproof Multi Pin Connector

    SRD.TGG.2K.308 8 Pin Electrical Connectors Multipole Waterproof Multi Pin ConnectorSRD.TGG.2K.308 8 Pin Electrical Connectors Multipole Waterproof Multi Pin Connector


    The most professional push-pull self-locking connector manufacturer provides the most professional, fast, stable and efficient connector application solution

    Send your message to us


    SRD.TGG General waterproof plug,with key(G)or(A..F,L,R)to avoid moving and mismatching,cable colet to fix cable,with sleeve to prevent the cable from bending.

    ReferenceDimensions (mm)
    ModelSeriesALMS2
    TGG0K1134237
    TGG1K1342289
    TGG2K16523612
    SRD.TGG.2K.308 8 Pin Electrical Connectors Multipole Waterproof Multi Pin Connector

    SRD.TGG.2K.308 8 Pin Electrical Connectors Multipole Waterproof Multi Pin Connector

    No.Outer Shell &ColletLatch sleeve& Grounding CrownOther Metal Component
    MaterialSurfaceMaterialSurfaceMaterialSurface
    CBrassPearl ChromeBrass/BronzeNickelBrassNickel
    NBrassNickelBrass/BronzeNickelBrassNickel
    KBrassBlack ChromeBrass/BronzeNickelBrassNickel
    SStainless SteelBrass/BronzeNickelBrassNickel
    TStainless SteelStainless SteelNickelBrassNickel
    UStainless SteelStainless SteelNickelStainless SteelNickel
    LAuminum AloyPositive Pole PlatedBrass/BronzeNickelBrassNickel
    XAuminum AloyBlack NickelBrass/BronzeNickelBrassNickel
