M16A connector 12 pin BEG waterproof aviation socket
Product features:
1. Waterproof grade IP67
2. Stable performance
3. Resistant to pressure and corrosion
4. High density assembly to save space
5. Pure copper gold-plated needle
M16 Circular Connector Technical Characteristics:
| Rated current | 6A |
| Test voltage (pin core - housing) | 1.35KV rms |
| Test voltage (pin core - pin core) | 1.25KV rms |
| Contact diameter | 0.7mm |
| Metallic material | Copper plated with pearl chrome and copper plated with gold |
| Core type | welding |
| durability | ≥1000 times |
| Maximum humidity | ≤95% [ at 60℃ / 140 F ] |
| Neutral salt spray | 96H |
Applications Of M16A 12 pin BEG waterproof aviation socket:
1. medical: medical imaging, cardiac assist devices, disposable
equipment, diagnostic devices, surgical instrumentation
2. broadcast: TV and motion picture, HD and SD cameras, remote
camero control, studios and outside broadcasting
3. instrumentation: test&measurement, sensors, data
acquisition, automation, scientific research, vacuum
4. transport: maritime, automotive, railways, avionics
FAQ
Q: Can you provide customization?
A: You’d better provide parameters of the cable and the
specification of the connector. If it’s for professional equipment
cable, please provide weld definition.
Q: Some connectors are available with different cables. Which
cables shall I choose?
A: Always choose the cable with the bigger diameter, because the
bigger diameter results in less attenuation.
Q: What can you buy from us?
A: Push-pull connectors, cable assembly, bayonet connectors,
military connctors, custom connectors.
Q: What about the leading time?
A: If there's stock, we ship th e goods within 3-5 working days
after the deposit is confirmed. Or else, it depends on the quantity
you need.
Q: What payment methods you support?
A: We accept T/T, Papal, Western Union, ect.
Q: How do you solve after sale service?
A: After the receipt of goods, if you are not satisfied or having
any other problems, please contact us as soon as possible, we will
give you a quick and reasonable solution.
